Image is for illustrative purposes only. Please refer to product description.
16 other products in the same category:
4.30 CHF
Availability: 191 In Stock
XGK Saia Microswitch
Reference : XGK14-81-S20 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 1.5 Circuit : Change-over Terminals : Print bent (base) Contacts : Gold-plated 4um (Au) on Ag Actuators : Roller lever 12.8 mm Approvals : ENEC
22.50 CHF
Microswitch MKV
25.40 CHF
Availability: 10 In Stock
Microswitch MKV
4.20 CHF
XGK Saia Microswitch
Reference : XGK7-88Z1 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 1.5 Circuit : Change-over Terminals : Screw Contacts : Ag / AgNi10 Actuators : Without lever Approvals : UL / CSA
2.00 CHF
XGA Saia Microswitch
Reference : XGA2-86-J23 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 3.2 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Ag / Ag CdO Actuators : Plain lever 27.8 mm Approvals : ENEC
20.10 CHF
Availability: 24 In Stock
V3 Burgess Microswitch
1.60 CHF
Availability: 45 In Stock
XCG Saia Microswitch
Reference : XCG3-J2Z1 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 1.7 Circuit : Change-over Terminals : Solder Contacts : Ag Actuators : Plain lever 25.0 mm Approvals : UL / CSA
22.00 CHF
Microswitch MKV
2.30 CHF
Availability: 3890 In Stock
XGK Saia Microswitch
Reference : XGK2-88-S21Z1 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 1.5 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Ag / AgNi10 Actuators : Roller lever Approvals : UL / CSA
35.90 CHF
Availability: 11 In Stock
V9N Burgess Microswitch
Reference : V9NLR1 Rating : 250 VAC / 10 A max. Dimensions (mm) : 42 x 24.5 x 16 Protection : IP67 Actuating Force (N) : 4.5 Circuit : Change-over Terminals : unwired Actuators : Roller lever 32.2 mm
1.40 CHF
Availability: 295 In Stock
V4N Saia Microswitch
Reference : V4NT8UL Rating : 250 VAC / 5A Dimensions (mm) : 20 x 10.3 x 6.4 Type of sealing : unsealed Terminals : PCB 0.8 x 0.5 x 4.0 long Circuit : Change-over Actuators : without lever Contact Material : Ag Approval : UL, CSA and ENEC approval
2.30 CHF
Availability: 200 In Stock
XCC Saia Microswitch
Reference : XCC13-J4 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 0.6 Circuit : Change-over Terminals : PCB. Formed to lid. 1/10'' pitch Contacts : Ag Actuators : Plain lever Approvals : ENEC
40.70 CHF
CT Saia Microswitch
1.30 CHF
Add to cart
Availability: Out of stock
XCC Saia Microswitch
Reference : XCC3 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 0.6 Circuit : Change-over Terminals : Solder Contacts : Ag Actuators : Without lever Approvals : ENEC
2.60 CHF
XGG Saia Microswitch
Reference : XGG3-88-S20Z1 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 3.2 Circuit : Change-over Terminals : Solder 1.7 x 3.2 Contacts : Ag / AgNi10 Actuators : Roller lever 12.8 mm Approvals : UL / CSA
1.90 CHF
XCC Saia Microswitch
Reference : XCC12 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 0.6 Circuit : Change-over Terminals : PCB. Formed to base. 1/10'' pitch Contacts : Ag Actuators : Without lever Approvals : ENEC
