Image is for illustrative purposes only. Please refer to product description.
16 other products in the same category:
2.00 CHF
Availability: 86 In Stock
XGA Saia Microswitch
Reference : XGA2-88 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 3.2 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Ag / AgNi10 Actuators : Without lever Approvals : ENEC
5.05 CHF
Availability: 18 In Stock
V4N Saia Microswitch
Reference : V4NSUL Rating : 250 VAC / 5A Dimensions (mm) : 20 x 10.3 x 6.4 Type of sealing : Sealed IP67 standard travel Terminals : Pre-wired Circuit : Change-over Actuators : without lever Contact Material : Ag Approval : UL, CSA and ENEC approval
3.20 CHF
Availability: 85 In Stock
V4L Burgess Microswitch
5.60 CHF
Availability: 112 In Stock
XP Burgess Mikroschalter NC + NO
Reference : XP2-E2Z11 Rating : 400 VAC / 16 A Dimensions (mm) : 30 x 32 x 12 Protection : IP40 enclosure Type : Momentary Actuating Force (N) : 3 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Silver Actuators : Mushroom plunger Approvals : UL / cUL / CSA and ENEC
11.50 CHF
Availability: 50 In Stock
V4N Saia Microswitch 3M Cable
Reference : V4NCSARG3000 Rating : 250 VAC / 5A Dimensions (mm) : 20 x 10.3 x 6.4 Type of sealing : Sealed IP6K7 standard travel Terminals : Pre-wired Circuit : Change-over Actuators : Roller lever 16.0 mm Contact Material : Gold plate on silver Approval : none
65.00 CHF
V9N Burgess Microswitch
Reference : V9NLR1V Rating : 250 VAC / 10 A max. Dimensions (mm) : 42 x 24.5 x 16 Protection : IP67 Actuating Force (N) : 4.5 Circuit : Change-over Terminals : Vertical pre-wired Actuators : Roller lever 32.2 mm
1.70 CHF
XCC Saia Microswitch
Reference : XCC3-L1Z1 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 0.6 Circuit : Change-over Terminals : Solder Contacts : Ag Actuators : Cam follower 16.0 mm Approvals : UL / CSA
2.90 CHF
Availability: 262 In Stock
Q Actuator Burgess Microswitch
2.00 CHF
XGA Saia Microswitch
Reference : XGA2-86-J23 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 3.2 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Ag / Ag CdO Actuators : Plain lever 27.8 mm Approvals : ENEC
4.15 CHF
Availability: 410 In Stock
XGK Saia Microswitch
Reference : XGK2-81-S20Z1 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 1.5 Circuit : Change-over Terminals : Faston 6.3 x 0.8 Contacts : Gold-plated 4um (Au) on Ag Actuators : Roller lever 12.8 mm Approvals : UL / CSA
222.60 CHF
Availability: 13 In Stock
XO6 Saia Microswitch
1.20 CHF
Availability: 258 In Stock
XCG Saia Microswitch
Reference : XCG4 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 1.7 Circuit : Change-over Terminals : plug 2.8 x 0.5 mm DIN Contacts : Ag Actuators : Without lever Approvals : ENEC
2.90 CHF
Availability: 245 In Stock
XCG Saia Microswitch
Reference : XCG13-S1 Rating : 250 VAC / 10 A max Dimensions (mm) : 19.9 x 9.5 x 6.4 Protection : Enclosure IP40 Actuating Force (N) : 1.7 Circuit : Change-over Terminals : PCB. Formed to lid. 1/10'' pitch Contacts : Ag Actuators : Roller lever 16.0 mm Approvals : ENEC
2.20 CHF
Availability: 33 In Stock
XGO Saia Microswitch
Reference : XGO3-88Z1 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 1.2 Circuit : Change-over Terminals : Solder 1.7 x 3.2 Contacts : Ag / AgNi10 Actuators : Without lever Approvals : UL / CSA
2.20 CHF
X3 Saia Microswitch
Reference : X3M502K2KA Rating : 250 VAC / 25 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : IP 40 enclosure Actuating Force (N) : 1.6 Circuit : Normally open (NO) Terminals : Plug terminal 6.3 x 0.8 mm Contacts : Silver / AgNi10 Actuators : Without lever
6.50 CHF
Availability: 30 In Stock
XGA Saia Microswitch
Reference : XGA19-88-S40 Rating : 250 VAC / 26 A max Dimensions (mm) : 27.8 x 15.9 x 10.3 Protection : Enclosure IP40 Actuating Force (N) : 3.2 Circuit : Change-over Terminals : Short solder Contacts : Ag / AgNi10 Actuators : Roller lever 12.8 mm Approvals : ENEC
