XCC8-J2

Ambient temperature:From -25°C to +85°C
Housing:Technopolymer housing
Terminal type:Screws with self-lifting plate
Contact block:1NO+1NC changeover
Maximum protection degree:Actuation type:Direct action
Actuator:With threaded M12x1 plunger
Positive opening:Yes

• Reference : XCG10
• Rating : 250 VAC / 10 A max
• Dimensions (mm) : 19.9 x 9.5 x 6.4
• Protection : Enclosure IP40
• Actuating Force (N) : 1.7
• Circuit : Change-over
• Terminals : PCB. Formed to base
• Contacts : Ag
• Actuators : Without lever
• Approvals : ENEC

Ambient temperature:From -25°C to +85°C
Housing:Technopolymer housing
Terminal type:Screws with self-lifting plate
Contact block:1NO+1NC changeover
Maximum protection degree:IP00 without terminal cover
IP20 with terminal cover VF C01, VF C03
IP40 with terminal cover VF MKCx1x, VF C02
Actuation type:Direct action
Actuator:With trasversal roller lever (l= 25mm)

• Reference : XGC7-88
• Rating : 250 VAC / 26 A max
• Dimensions (mm) : 27.8 x 15.9 x 10.3
• Protection : Enclosure IP40
• Actuating Force (N) : 0.8
• Circuit : Change-over
• Terminals : Screw
• Contacts : Ag / AgNi10
• Actuators : Without lever
• Approvals : ENEC

• Reference : V9NLV
• Rating : 250 VAC / 10 A max.
• Dimensions (mm) : 42 x 24.5 x 16
• Protection : IP67
• Actuating Force (N) : 3
• Circuit : Change-over
• Terminals : Vertical pre-wired
• Actuators : Plain lever 44.5 mm

• Reference : XCG3V-81
• Rating : 250 VAC / 10 A max
• Dimensions (mm) : 19.9 x 9.5 x 6.4
• Protection : Enclosure IP40
• Actuating Force (N) : 1.7
• Circuit : Change-over
• Terminals : Solder
• Contacts : u profile Au 10 um
• Actuators : Without lever
• Approvals :

• Reference : V4NSYRGUL
• Rating : 250 VAC / 5A
• Dimensions (mm) : 20 x 10.3 x 6.4
• Type of sealing : Sealed IP67 standard travel
• Terminals : Pre-wired
• Circuit : Change-over
• Actuators : Roller lever 16.0 mm
• Contact Material : gold plate on silver
• Approval : UL, CSA and ENEC approval

• Reference : XGK2-81-S20Z1
• Rating : 250 VAC / 26 A max
• Dimensions (mm) : 27.8 x 15.9 x 10.3
• Protection : Enclosure IP40
• Actuating Force (N) : 1.5
• Circuit : Change-over
• Terminals : Faston 6.3 x 0.8
• Contacts : Gold-plated 4um (Au) on Ag
• Actuators : Roller lever 12.8 mm
• Approvals : UL / CSA

Ambient temperature:From -25°C to +85°C
Housing:Technopolymer housing
Terminal type:Screws with self-lifting plate
Contact block:1NO+1NC changeover
Maximum protection degree:Actuation type:Direct action
Actuator:With threaded M12x1 plunger
Positive opening:Yes

• Reference : XCG10
• Rating : 250 VAC / 10 A max
• Dimensions (mm) : 19.9 x 9.5 x 6.4
• Protection : Enclosure IP40
• Actuating Force (N) : 1.7
• Circuit : Change-over
• Terminals : PCB. Formed to base
• Contacts : Ag
• Actuators : Without lever
• Approvals : ENEC

Ambient temperature:From -25°C to +85°C
Housing:Technopolymer housing
Terminal type:Screws with self-lifting plate
Contact block:1NO+1NC changeover
Maximum protection degree:IP00 without terminal cover
IP20 with terminal cover VF C01, VF C03
IP40 with terminal cover VF MKCx1x, VF C02
Actuation type:Direct action
Actuator:With trasversal roller lever (l= 25mm)

• Reference : XGC7-88
• Rating : 250 VAC / 26 A max
• Dimensions (mm) : 27.8 x 15.9 x 10.3
• Protection : Enclosure IP40
• Actuating Force (N) : 0.8
• Circuit : Change-over
• Terminals : Screw
• Contacts : Ag / AgNi10
• Actuators : Without lever
• Approvals : ENEC
