- Single-phase energy meter, 230 VAC 50 Hz
- Direct measurement up to 32 A
- Display of active power, voltage and current
- 7-digit LC-Display with backlight
- Lead seal possible with cap as accessory
- Precision class B according to EN50470-3,
  1 according to IEC62053-21
- S0 output

Main features
- Single-phase energy meter, 230 VAC 50 Hz
- Direct measurement up to 32 A
- Display of active power, voltage and current
- M-Bus Interface to query the data
- Reactive power available through interface
- Up to 250 meter can be connected to the M-Bus Interface
- 7-digit display
- Lead seal possible with cap as accessory
- Accuracy class B according to EN50470-3, accuracy class 1 according to IEC62053-21

Order Number
Standard Version: ALD1D5FS00A2A00
MID Version: ALD1D5FS00A3A00
Sealing caps: 4 104 7420 0
Main features
- Single-phase energy meter, 230 VAC 50 Hz
- Direct measurement up to 32 A
- Display of active power, voltage and current
- S-Bus Interface to query the data
- Reactive power and cos PHI available through interface
- Up to 254 meter can be connected to the S-Bus Interface
- 7-digit display
- Lead seal possible with cap as accessory
- Accuracy class B according to EN50470-3, accuracy class 1 according to IEC62053-21

Three-phase two-way energy meter with LCD display
- Modbus interface, Imax = 65 A
- display of active power, voltage and current
- according to MID directive

Three-phase two-way energy meter with LC display and S-Bus interface
- 3-phase energy meter, 3 × 230 / 400 VAC 50 Hz
- Direct metering to 65 A in both directions of current
- Display of the active power, voltage and current per phase
- Display of the total active power
- S-bus interface used to query data
- Idle power per phase or total available via the interface
- Up to 254 energy meters can be connected to a single S-bus interface
- 7-digit LCD display for energy supply and feeding back
- Can be sealed and is provided with a sealing cap as an accessory
- Accuracy class B in accordance with EN50470-3,
  Accuracy class 1 in accordance with IEC62053-21
- according to MID directive

Three-phase energy meter with LCD display
- S0 pulse output = 1'000 pulses/kWh
- Imax = 65 A, 2 tariffs
- display of active power, voltage and current
- display without main power (backup)
- according to MID directive

Three-phase energy meter with LCD display
- M-Bus interface, Imax = 65 A, 2 tariffs
- display of active power, voltage and current
- according to MID directive

Three-phase two-way energy meter with LC display and S-Bus interface
- 3-phase energy meter, 3 × 230 / 400 VAC 50 Hz
- Direct measurement up to 65 A
- Display of active power, voltage and current for every phase
- display="" of="" active="" power="" for="" all="" phase<br="">- S-Bus Interface to query the data
- Reactive power for every and/or all Phase available through interface
- Up to 254 meter can be connected to the S-Bus Interface
- 7-digit display for 1 or 2 tariffs
- Lead seal possible with cap as accessory
- Accuracy class B in accordance with EN50470-3,
  Accuracy class 1 in accordance with IEC62053-21
- according to MID directive

Three-phase two-way energy meter with LCD display
S-Bus interface, 5…1'500 A
display of active power, voltage and current
according to MID directive

3-phase energy meter, 3 × 230 / 400 VAC 50 H
- Measurement through a current transformer up to 1500 A
- Display of active power, voltage and current for every phase
- Display of active power for all phases
- Modbus RTU Interface to query the data
- Reactive power for every and/or all Phases available through interface
- Up to 247 meters can be connected to the Modbus Interface
- 7-digits display
- Lead seal possible with cap as accessory
- Accuracy class B according to EN50470-3,
  accuracy class 1 according to IEC62053-21
- according to MID directive

- Measurement through a current transformer up to 1500 A
- Display of energy, instantaneous power, voltage and current
- Display of the total active power
- M-Bus interface to retrieve the data
- Reactive power per phase or total, available via M-Bus interface
- Up to 250 meters can be addressed trough primary addresses
- 7-character display
- Can be sealed with sealing cap (optional)
- Accuracy class B according to EN50470-3, accuracy class 1 according to IEC62053-21

• Reference : CMA062M4N0N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 999999
• Reset : Without
• Connections : Stranded wire 150mm
• Voltage : 24 VDC

• Reference : CMA152E1N0N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 99999
• Reset : With
• Connections : Stranded wire 150mm
• Voltage : 220 to 240 VAC

• Reference : CMA152M1N0N0N00
• Type : Electromechanical disply counters
• Mounting : Flush mounting
• Counting capacity : 99999
• Reset : With
• Connections : Stranded wire 150mm
• Voltage : 12 VDC

• Reference : CMA152M4N0N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 99999
• Reset : With
• Connections : Stranded wire 150mm
• Voltage : 24 VDC

• Reference : CMB062M4N1N0N46
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Stranded wire 150 mm
• Voltage : 12 VDC

• Reference : CMB072E1N1N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Stranded wire 150 mm
• Voltage : 220 to 240 VAC

• Reference : CMB072M1N1N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Stranded wire 150 mm
• Voltage : 12 VDC

• Reference : CMB072M4N1N0N00
• Type : Electromechanical display counters
• Mounting : Flush mounting
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Stranded wire 150 mm
• Voltage : 24 VDC

• Reference : CMB079D1N1N0N00
• Type : Electromechanical display counters
• Mounting : Surface mounting for DIN rail
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Connection terminals 2 x 2.5mm2
• Voltage : 110 to 120 VAC

• Reference : CMB970M1N1N0N00
• Type : Electromechanical display counters
• Mounting : Machine solderable and washable plug-in on printed circuit board
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Solder pins 0.4 x 1.2mm
• Voltage : 12 VDC

• Reference : CMB970M4N2N0N00
• Type : Electromechanical display counters
• Mounting : Machine solderable and washable plug-in on printed circuit board
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC 25 pulses/s
• Connections : Solder pins 0.4 x 1.2mm
• Voltage : 24 VDC

• Reference : CMB976M1N1N0N00
• Type : Electromechanical display counters
• Mounting : Machine solderable and washable plug-in on printed circuit board
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Solder pins 0.4 x 1.2mm
• Voltage : 12 VDC

• Reference : CMB976M1N2N0N12
• Type : Electromechanical display counters
• Mounting : Machine solderable and washable plug-in on printed circuit board
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC 25 pulses/s
• Connections : Solder pins 0.4 x 1.2mm
• Voltage : 12 VDC

• Reference : CMB976M4N1N0N00
• Type : Electromechanical display counters
• Mounting : Machine solderable and washable plug-in on printed circuit board
• Counting capacity : 9999999
• Reset : Without
• Couting frequency : DC or AC (all voltages) 10 pulses/s
• Connections : Solder pins 0.4 x 1.2mm
• Voltage : 24 VDC
