Stations d’automatisation

Manual override operating level for all outputs
Status LED for outputs
Supply 24 VDC
- 10 digital outputs 24 VDC (12…32 VDC/0.5 A)
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB service interface

E-Line S-Serie digital output module
manual override operating level for all outputs
status LED for outputs
supply 24 VDC
- 6 relay normally open 230 VAC / 30 VDC 16 A (resistive load)
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line digital input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 4 digital inputs 24 VDC (source operation)
- 6 relay normally open 230 VAC / 30 VDC 4 A (resistive load)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 1 interface RS-485 (S-Bus and Modbus)

E-Line digital input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 24 digital inputs 24 VDC (source operation)
- 6 relay normally open 230 VAC / 30 VDC 4 A (resistive load)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 1 interface RS-485 (S-Bus and Modbus)

E-Line digital input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 16 digital inputs 24 VDC (source operation)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 1 interface RS-485 (S-Bus and Modbus)

E-Line S-Serie Digital input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 4 digital inputs; 24 VDC (source operation)
- 10 relay (6 normally open/ 4 changeover) 250 VAC / 30 VDC 5 A (DC1)
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line S-Serie Digital input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 16 digital inputs; 24 VDC (source operation)
- 4 relay changeover 250 VAC / 30 VDC 5 A (DC1)
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line S-Serie Digital input module
status LED for inputs
supply 24 VDC
- 12 Digital inputs 24 VDC (source operation)
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB service interface

E-Line S-Serie combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 6 universal digital/analogue inputs
    - digital inputs 24 VDC
    - analoque inputs 12 bits
      0…10 V Pt/Ni 1000 Ni 1000 L&S NTC
      0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 2 analogue outputs 10 bits 0…10 V
- 2 triac outputs 24 VAC/1 A or 230 VAC/1 A
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line S-Serie combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 8 universal digital/analogue inputs
   - digital inputs 24 VDC
   - analoque inputs 12 bits
     0…10 V Pt/Ni 1000 Ni 1000 L&S NTC
     0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line S-Serie combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 8 universal digital/analogue inputs
   - digital inputs 24 VDC
   - analoque inputs 12 bits
     0…10 V Pt/Ni 1000 Ni 1000 L&S NTC
     0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 4 analogue outputs 10 bits 0…10 V
- 1 interface RS-485 (S-Bus and Modbus)
- 1 USB Service interface

E-Line combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 16 digital inputs 24 VDC (source operation)
- 4 relay normally open 230 VAC / 30 VDC 4 A (resistive load)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 8 analogue inputs 12 bits
     0…10 V Pt/Ni 1000 Ni 1000 L&S NTC 0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 4 analogue outputs 10 bits 0…10 V (10 mA max.)
- 1 interface RS-485 (S-Bus and Modbus)

E-Line combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 12 digital inputs 24 VDC (source operation)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 12 analogue inputs 12 bits
     0…10 V Pt/Ni 1000 Ni 1000 L&S NTC 0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 8 analogue outputs 10 bits 0…10 V (10 mA max.)
- 1 interface RS-485 (S-Bus and Modbus)

E-Line combined input/output module
manual override operating level for all outputs
status LED for inputs and outputs
supply 24 VDC
- 8 digital inputs 24 VDC (source operation)
- 4 relay changeover 230 VAC / 30 VDC 4 A (resistive load)
- 16 analogue inputs 12 bits
     0…10 V Pt/Ni 1000 Ni 1000 L&S NTC 0…2500 Ohm 0…7500 Ohm 0…300 kOhm
- 4 analogue outputs 10 bits 0…10 V (10 mA max.)
- 1 interface RS-485 (S-Bus and Modbus)
