Image is for illustrative purposes only. Please refer to product description.
HC385XLG-011
Indicative price (excluding VAT)
15.34 €
Discount available on request
Quantity available:
FR : 0
CH : 47
LVDC Motor 1999-Z030007Ep
FR : 0 CH : 47LVDC Motor 1999-Z030007Ep
Guarantee safe & secure checkout
Dimensions : Ø 27.5 X 46.5 mm
Shaft Diameter : Ø 2.305 mm
Input Voltage : 36.0 V DC
No Load Speed : 11000 rpm
No Load Current : 0.10 A
Nominal Speed : 9700 rpm
Nominal Torque : 13.00 mNm
Nominal Current : 0.50 A
Stall Torque : 90.00 mNm
Stall Current : 3.00 A
Maximum Output Power : 25.00 W
Maximum Efficiency : 70 %
Torque at Maximum Efficiency : 12.00 mNm
Speed at Maximum Efficiency : 9500 rpm
Life (typical) : 150 hr
Weight : 90 g
Operation Temperature :-10 to 55°C
Storage Temperature :-20 to 80°C
Electrical Connection : terminals
