- New
Image is for illustrative purposes only. Please refer to product description.
XGO15-88
2.20 CHF
Tax excluded
XGO Saia Microswitch
- Reference : XGO15-88
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 1.2
- Circuit : Change-over
- Terminals : Rast 5 6.3 x 0.8
- Contacts : Ag / AgNi10
- Actuators : Without lever
- Approvals : ENEC
Guarantee safe & secure checkout
16 other products in the same category:
XGK7-88-S21
7.60 CHF
Availability: Out of stock
XGK Saia Microswitch
- Reference : XGK7-88-S21
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 1.5
- Circuit : Change-over
- Terminals : Screw
- Contacts : Ag / AgNi10
- Actuators : Roller lever
- Approvals : ENEC
XGK12-81
3.60 CHF
Availability: 1085 In Stock
XGK Saia Microswitch
- Reference : XGK12-81
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 1.5
- Circuit : Change-over
- Terminals : Short solder D2.3
- Contacts : Gold-plated 4um (Au) on Ag
- Actuators : Without lever
- Approvals : ENEC
XTD22AZ1
6.80 CHF
Availability: 651 In Stock
XTD Burgess Microswitch
- Reference : XTD22AZ1
- Rating : 400 VAC / 16.5 A max
- Dimensions (mm) : 30 x 32 x 12
- Protection : IP40 enclosure
- Actuating Force (N) : 3.8
- Circuit : Normally open (NO)
- Terminals : 6.3 x 0.8 mm faston terminals
- Contacts : Silver nickel
- Actuators : Snap-on mounting with shroud
XGK2-88-J22Z1
2.00 CHF
Availability: 607 In Stock
XGK Saia Microswitch
- Reference : XGK2-88-J22Z1
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 1.5
- Circuit : Change-over
- Terminals : Faston 6.3 x 0.8
- Contacts : Ag / AgNi10
- Actuators : Plain lever 24.0 mm
- Approvals : UL / CSA
XCG5Z1
1.40 CHF
Availability: 4173 In Stock
XCG Saia Microswitch
- Reference : XCG5Z1
- Rating : 250 VAC / 10 A max
- Dimensions (mm) : 19.9 x 9.5 x 6.4
- Protection : Enclosure IP40
- Actuating Force (N) : 1.7
- Circuit : Change-over
- Terminals : Plug 2.8 x 0.5 mm AMP
- Contacts : Ag
- Actuators : Without lever
- Approvals : UL / CSA
XCF3-J1Z1
1.60 CHF
Availability: 3720 In Stock
XCF Saia Microswitch
- Reference : XCF3-J1Z1
- Rating : 250 VAC / 10 A max
- Dimensions (mm) : 19.9 x 9.5 x 6.4
- Protection : Enclosure IP40
- Actuating Force (N) : 3
- Circuit : Change-over
- Terminals : Solder
- Contacts : Ag
- Actuators : Plain lever 18.0 mm
- Approvals : UL / CSA
XTD22APZ1
5.50 CHF
Availability: 145 In Stock
XTD Burgess Microswitch
- Reference : XTD22APZ1
- Rating : 400 VAC / 16.5 A max
- Dimensions (mm) : 30 x 32 x 12
- Protection : IP40 enclosure
- Actuating Force (N) :
- Circuit : Normally open (NO)
- Terminals : 6.3 x 0.8 mm faston terminals
- Contacts : Silver nickel
- Actuators : Without shroud. Without snap-on mounting
XCG12
2.10 CHF
Availability: 3 In Stock
XCG Saia Microswitch
- Reference : XCG12
- Rating : 250 VAC / 10 A max
- Dimensions (mm) : 19.9 x 9.5 x 6.4
- Protection : Enclosure IP40
- Actuating Force (N) : 1.7
- Circuit : Change-over
- Terminals : PCB. Formed to base. 1/10'' pitch
- Contacts : Ag
- Actuators : Without lever
- Approvals : ENEC
XGG2-88-S20Z1
2.50 CHF
Availability: 3100 In Stock
XGG Saia Microswitch
- Reference : XGG2-88-S20Z1
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 3.2
- Circuit : Change-over
- Terminals : Faston 6.3 x 0.8
- Contacts : Ag / AgNi10
- Actuators : Roller lever 12.8 mm
- Approvals : UL / CSA
XGC7-88
2.90 CHF
Availability: 1 In Stock
XGC Saia Microswitch
- Reference : XGC7-88
- Rating : 250 VAC / 26 A max
- Dimensions (mm) : 27.8 x 15.9 x 10.3
- Protection : Enclosure IP40
- Actuating Force (N) : 0.8
- Circuit : Change-over
- Terminals : Screw
- Contacts : Ag / AgNi10
- Actuators : Without lever
- Approvals : ENEC
