Energy meters
Energy meters
The very compact design makes the SBC energy meters ideally suited to accommodate a large number of measuring instruments in the smallest space. The small size means the meters can also be fitted in existing switch cabinets without having to install new switch cabinets. The robust design has certainly proven itself under tough industrial conditions. The design of the energy meters is specifically designed for such applications, as is shown by a high level of reliability and durability. The display shows energy, current, voltage and active output.
There are 12 products.
ALD1D5F10KB3A00
FR : 0
CH : 3
Single-phase energy meter with LCD display S0 pulse output = 1'000 pulses/kWh Im
- Single-phase energy meter, 230 VAC 50 Hz
- Direct measurement up to 32 A
- Display of active power, voltage and current
- 7-digit LC-Display with backlight
- Lead seal possible with cap as accessory
- Precision class B according to EN50470-3,
1 according to IEC62053-21
- S0 output
ALD1D5FM00A3A00
Quantity available:
FR : 0
CH : 1
Single-phase energy meter with LCD display M-Bus interface Imax = 32 A 1 tarif
ALD1D5FS00A3A00
FR : 0
CH : 1
Single-phase energy meter with LCD display S-Bus interface Imax = 32 A 1 tarif
Order Number
Standard Version: ALD1D5FS00A2A00
MID Version: ALD1D5FS00A3A00
Sealing caps: 4 104 7420 0
Main features
- Single-phase energy meter, 230 VAC 50 Hz
- Direct measurement up to 32 A
- Display of active power, voltage and current
- S-Bus Interface to query the data
- Reactive power and cos PHI available through interface
- Up to 254 meter can be connected to the S-Bus Interface
- 7-digit display
- Lead seal possible with cap as accessory
- Accuracy class B according to EN50470-3, accuracy class 1 according to IEC62053-21
ALE3B5FD00C3A00
FR : 0
CH : 1
Three-phase two-way energy meter with LCD display Modbus interface Imax = 65 A
Three-phase two-way energy meter with LCD display
- Modbus interface, Imax = 65 A
- display of active power, voltage and current
- according to MID directive
ALE3B5FS00C3A00
FR : 0
CH : 2
Three-phase two-way energy meter with LCD display S-Bus interface Imax = 65 A d
Three-phase two-way energy meter with LC display and S-Bus interface
- 3-phase energy meter, 3 × 230 / 400 VAC 50 Hz
- Direct metering to 65 A in both directions of current
- Display of the active power, voltage and current per phase
- Display of the total active power
- S-bus interface used to query data
- Idle power per phase or total available via the interface
- Up to 254 energy meters can be connected to a single S-bus interface
- 7-digit LCD display for energy supply and feeding back
- Can be sealed and is provided with a sealing cap as an accessory
- Accuracy class B in accordance with EN50470-3,
Accuracy class 1 in accordance with IEC62053-21
- according to MID directive
ALE3D5F11KC3A00
FR : 0
CH : 0
Three-phase energy meter with LCD display S0 pulse output = 1'000 pulses/kWh
Three-phase energy meter with LCD display
- S0 pulse output = 1'000 pulses/kWh
- Imax = 65 A, 2 tariffs
- display of active power, voltage and current
- display without main power (backup)
- according to MID directive
ALE3D5FM10C3A00
Quantity available:
FR : 0
CH : 1
Three-phase energy meter with LCD display M-Bus interface Imax = 65 A 2 tariff
ALE3D5FS10C3A00
FR : 0
CH : 2
Three-phase energy meter with LCD display S-Bus interface Imax = 65 A 2 tariff
Three-phase two-way energy meter with LC display and S-Bus interface
- 3-phase energy meter, 3 × 230 / 400 VAC 50 Hz
- Direct measurement up to 65 A
- Display of active power, voltage and current for every phase
- display="" of="" active="" power="" for="" all="" phase<br="">- S-Bus Interface to query the data
- Reactive power for every and/or all Phase available through interface
- Up to 254 meter can be connected to the S-Bus Interface
- 7-digit display for 1 or 2 tariffs
- Lead seal possible with cap as accessory
- Accuracy class B in accordance with EN50470-3,
Accuracy class 1 in accordance with IEC62053-21
- according to MID directive
AWD3B5WS00C3A00
Quantity available:
FR : 0
CH : 1
Three-phase two-way energy meter with LCD display S-Bus interface 5…1'500 A dis
AWD3D5WD00C3A00
FR : 0
CH : 1
Three-phase energy meter with LCD display Modbus interface 5…1'500 A 1 tariff
3-phase energy meter, 3 × 230 / 400 VAC 50 H
- Measurement through a current transformer up to 1500 A
- Display of active power, voltage and current for every phase
- Display of active power for all phases
- Modbus RTU Interface to query the data
- Reactive power for every and/or all Phases available through interface
- Up to 247 meters can be connected to the Modbus Interface
- 7-digits display
- Lead seal possible with cap as accessory
- Accuracy class B according to EN50470-3,
accuracy class 1 according to IEC62053-21
- according to MID directive
AWD3D5WM00C3A00
Quantity available:
FR : 0
CH : 1
Three-phase energy meter with LCD display M-Bus interface 5…1'500 A 1 tariff d
